ETS异形插件机E-600
| ■技术规格参数 | |||||||
| 项目 | Items | E-600 | |||||
| 插入速度 | Insertion speed | 0.6S/ PCS (Gripper) | |||||
| 0.6S/ PCS (Vacuum) | |||||||
| 插入精度 | Insertion accuracy | ± 0.03mm | |||||
| 3mm-25mm | |||||||
| 元件高度© | Component height | 30mm | |||||
| 选攻(Option) | |||||||
| 插入方向 | Insertion direction | 0-360° | |||||
| Max 50mm-350mm | |||||||
| 基板厚度 | PCB Thickness | 0.8-5.0mm | |||||
| Max 5kg | |||||||
| 导轨高度* | Rail height | 900mm±20 | |||||
| 连接器.端口插座.开关按钮. 电容器件、变压器.集成芯片等 Connector, outlet port, switch button, capacitor, transformer, chip | |||||||
| 可配置供料 | Feeder type | 散装、带装.管装.盘装.多盘装 Bulk, Tape, Tube, Tray and Auto-Tray Feede | |||||
| 6 | |||||||
| 机器尺寸 （宽.深.高） | Machine dimension (L*W*H) | 1400mm* 1400mm* 1600mm | |||||
| 1550KG | |||||||
| 使用电源 | Power supply | 220VAC (single phase) 50HZ | |||||
| 4KVA | |||||||
| 工作气压 | Operation air pressure | 0.5±0.05MPa | |||||
| 70 60 l/min | |||||||
| 使用环境温度 | Operation temperalure | 5-30°C | |||||
| 70dB | |||||||
| 档案导入格式 | Upload file format | TXT | |||||
| Incoming pin detection | 相机定位检测 Camera location detection | ||||||
